Coffeum Cr1 - 1kg Drum Capacity Coffee Roasters
CoffeumCr1 roasts coffee perfectly for you.
CoffeumCr1 is shop type coffee roasters and more than sample roasting it has everything you need to start new cafe shop or cafe start
-
Perfect roasting from 300gr to 1kg (max.1,1kg).
-
5,5kg/hr Roasting Capacity
-
Versatile and flexible with production capacity.
-
Powerful Electric Heating or Gas Heating Burner
-
Sturdy and Extra Thick Steel Material,
A great start for Small Coffee Shop or Cafe
It creates efficient coffee roasting results for your business with its perfect roasting and flexibility in capacity.
Batch Size
Maximum 1,1 kg Drum Capacity, Minimum 300gr coffee roasting.
Cooling of Roasted Beans
Fast Cooling, Cooling Mixer and Cooling Fan Speed Control
Electric Voltage Compitable
Single Phase, 110-220-230-240V
Three Phase, 380-415V
Heating of Drum
Electric Heating Propane/Natural/Butane Gas
Burner
Double Wall Drum
13mm Drum Thickness
Special Steel Drum
Touch Panel Automatic Roasting
Automatic Coffee Roasting
Automatic Profile Repeat
Also Artisan and Cropters Connect
Motors
4 engines,
Roasting and cooling at the same time
Speed Control
Drum Rotation Speed Control
Exhaust fan (AirFlow) Speed Control
Certifications
CE Certificate
ISO Quality
UL Certificate
%100 Handmade
All our machines are handmade with high quality steel and materials and top class craftsmanship.
Cyclone Included
Thanks to its special and efficient cyclone structure, you collect the coffee husks with 100% performance.
Robust / Strong
Ideal for years of trouble-free use and growing your business with confidence.
Nonstop Roasting
You can also empty the cyclone shell tank while continuing to roast coffee. Nonstop coffee roasting!
Flexible Capacity
Coffeum Cr1 supports you with its large capacity and production flexibility.
Minimum Operating Cost
You work with high efficiency, and reduce your operating costs.
High Efficiency
It has the ability to roast in 10-12minutes.You can roast coffee and cool the roasted coffee at the same time
Roasting Passion
Let’s start roasting with Coffeum Cr1 for delicious coffee!
Coffeum Cr1 Coffee Roasters Features
Exceptional Quality
General View
Batch Size
300gr- max.1,1kg
Heating Type
Electric Heating or Propane/Natural/Butane Gas Burner
Certifications
CE Certificate
ISO Quality
UL Certificate
Features
Operating Tempature
0 - 250 degrees Celcius
(32 - 482 degrees Fahrenheit)
Heating Power 20.000 btu/h
Roasting Time
Light Roasting Time / Capacity kg/hr
8-10 minute 7,7 – 6,6 kg/hr
Dark Roasting Time / Capacity kg/hr
10-12 minute 6,6 – 5,5 kg/hr
Dimensions
Height 160cm
Width 80cm
Length 120cm
Chimney Outlet Dimension 130mm
Weight 150kg
Included Standard
2pcs Speed Control
Drum Rotation Speed Control
Exhaust fan (AirFlow) Speed Control
Control
2pcs Digital Temperature Control System and Indicator
Electric Heating Adjustment
Automatic Gas Control
Manuel Gas Potentiometer
Extra Exhaust Flap
Gas pressure control and indicator
Motors
4pcs Motors
With our special system, It can run three-phase motors with two phases electricity.
Thus, you have the efficiency and robustness of industrial machines.
Standard Equipments
Roasting Details
Sample Observation Glass
Sample Spoon
Audible Warning System
Simultaneous Roasting and Cooling
(4 Motor Power)
Emergency Stop Button
Sound and Light Warning Alarm
Roasting Details
High Capacity Cyclone and Coffee Husk Storage.
Non-stop roasting with the possibility of emptying the coffee husk storage while roasting.
Cooling area husk collector drawer.
Easy Maintenance and Cleaning.
Roasting Details
1pc Exhaust Fan - 1pc Cooling Fan
Combinable high efficiency two flue outlets.
13mm Drum Thickness Special Steel Double Drum
Standard 4.3" touch screen: shows ROR,DTR, TP, FS,SC, Bean and Exhaust Tempature and Timer
Standard Artisan and Cropters Connect
Extra Options
Colors
Body and Roof Color
All RAL Colors can be selected
Touch Panel Automatic Roasting
Automatic Coffee Roasting
Automatic Profile Repeat
7" Touch Panel Option
10" Touch Panel Option
Electric Voltage Compitable
Single Phase, 110-220-230-240V
Three Phase, 380-415V
Compatible Accessories and Options
Compatible Machines
Destoner
Safely separates foreign objects in your roasted coffee.
Afterburner
It burns 100% of the smoke coming out of the Roaster’s exhaust. Zero emissions
Green Coffee Conveyor
Easily load the green coffees to your roaster with no damage
Electrostatic Filter
It retains smoke and dust with an electrostatic filter and reduces emissions.
Roasters Options
Fully Automatic PLC System with Touch Panel
The Roaster automatically performs roasting with one click. It cools the coffee and load it into storage.
Making your custom logo on Roaster
Extra Sensors
Fire extinguishing system
Installation
Support
Guarantee
Transport
Installation
The Roasters is shipped ready for use.
We send all the necessary parts for Electricity, Gas and Chimney connections. All you have to do is press the START button after connecting the electricity, gas and chimney.
Everything has been made easier for you.
Extremely simple to use, easy to maintain, long-lasting and powerful Coffee Roaster.
Support
We are always here for you with our 24/7 support line.
All usage, maintenance and cleaning instructions are explained in detail in the user manual and in the videos that will be sent to you.
Our quality Coffee Roaster will be at your service non-stop for years.
-
GUARANTEE
5-year Parts and Labor Warranty.
We Trust Our Machine!
Transport
CIF, CIP, DAB, FOB, EXW
Air freight
Road transport
Boat transport
Door delivery service to your address.
Port Delivery service
We apply the safest and easiest delivery methods for you and deliver your order as quickly as possible.
